2013-P Fort McHenry Quarter Die Varieties
Doubled Die Reverses
| Designation | Description | Image |
|---|---|---|
| SDDR-001 | Cross-References: WDDR-001 | |
| Designation | Description | Image |
| SDDR-002 | Cross-References: WDDR-005 | |
| Designation | Description | Image |
| SDDR-003 | Cross-References: DDR-006, WDDR-003 | |
| Designation | Description | Image |
| SDDR-004 | Cross-References: WDDR-008 | |
| Designation | Description | Image |
| SDDR-005 | Doubling to the west on the right side of both firework bursts, two of the lower stripes of the flag, and very slightly on the wall. Very similar to SDDR-006 except the doubling on the fireworks is stronger and the doubled stripes are weaker. Also has slight doubling on the wall, unlike SDDR-006. Cross-References: DDR-003, WDDR-004 Die Markers: Obverse: Light die scratches in and below the UN in UNITED, only die scratches below the letters are visible in later die states. Die gouge inside the U in UNITED. Die gouge inside the G in GOD. Die gouge inside the lower portion of the E in AMERICA. Reverse: Light die pitting touches the firework burst below the F in FORT. Die gouge below the RY in McHENRY. Numerous die gouges above the fort to the left of the flagpole. |  |
| Designation | Description | Image |
| SDDR-006 | Doubling to the west on the right side of both firework bursts and two of the lower stripes of the flag. Very similar to SDDR-005 except the doubling on the fireworks is weaker and the doubled stripes are stronger. Does not have slight doubling on the wall, unlike SDDR-005. Cross-References: WDDR-014/015 Die Markers: Obverse: Die crack runs across the bust above the designers initials JF with two die chips just left of the J and another die chip far right of the F. Die chip on the bust above the E in QUARTER. Die gouge below the right side of the M in AMERICA. Reverse: Die gouge below the EN in McHENRY. Die chip or gouge touches the bottom of one of the shorter, lower-left firework bursts. Two die gouges between the roof of the fort and the firework bursts. |  |
| Designation | Description | Image |
| SDDR-007 | Doubling to the south on the right side of both firework bursts and below the bottom stripe of the flag. Cross-References: DDR-007, WDDR-002 Die Markers: Obverse: Die gouge just below the queue above the right side of the A in DOLLAR. Die gouge on the front tip of the bust. Reverse: Die gouge to the right of one of the firework bursts below the E in McHENRY. |  |
| Designation | Description | Image |
| SDDR-008 | Cross-References: DDR-005, WDDR-012 | |
| Designation | Description | Image |
| SDDR-009 | Cross-References: DDR-004, WDDR-006 | |
| Designation | Description | Image |
| SDDR-010 | Cross-References: DDR-002 | |
| Designation | Description | Image |
| SDDR-011 | Very strong extra thickness on most of reverse design most noticeable on firework bursts, the window frames, and the designers initials JFM. Cross-References: WDDR-007 Die Markers: Obverse: Stage A: Die gouge inside the C in AMERICA. Die gouge below the right side of the N in UNITED. Die gouge above the R in LIBERTY. Die gouge in front of the chin. Stage B: Stage A markers no longer present. Die gouge inside the lower portion of the E in QUARTER. Reverse: Stage A: Die gouges between the firework bursts and the fort roof. Stage B: Stage A markers no longer present. Numerous die chips formed in the firework bursts. Large die gouge left of the firework burst below the M in McHENRY. |  |
| Designation | Description | Image |
| SDDR-012 | Cross-References: WDDR-011 | |
| Designation | Description | Image |
| SDDR-013 | Cross-References: WDDR-013 | |
| Designation | Description | Image |
| SDDR-014 | Spread to the north on the doorway floor and part of the fort roof. Slight doubling on lower right firework bursts can be visible on Stage A. Cross-References: WDDR-009 Die Markers: Obverse: Stage A: Die scratch runs SW from the chin. Stage B: Stage A die scratch extremely weak and may not be visible. Die gouge in and above the O in DOLLAR. Two die gouges on the nose. Reverse: Stage A: None known. Stage B: Die gouges below the right side of the flag. |  |
| Designation | Description | Image |
| SDDR-015 | Cross-References: WDDR-010 | |
| Designation | Description | Image |
| SDDR-016 | Lower right firework burst slightly doubled to the south. Die Markers: Obverse: Stage A: Many die gouges around the two Ls in DOLLAR. Die gouge inside the C in AMERICA. Stage B: Die gouge in the C no longer visible. Die gouges around the Ls still visible. Reverse: Stage A: Die gouge in the area between the lower right firework bursts. Many die scratches in the same area. Stage B: Die scratches no longer present. Die gouge still present. |  |
| Designation | Description | Image |
| SDDR-017 | Lower right firework burst slightly doubled to the south. Die Markers: Obverse: Die gouges below the RT in LIBERTY. Reverse: Die gouge above the left side of the fort roof. |  |
